| Microphone input | Electronically balanced |
| Frequency Response to Main Output | 22Hz ~ 20KHz at 0dBu ±1.5dBu |
| Distortion (THD&N) to Main Output | <0.03% at 0dBu 1KHz |
| Gain | 0dBu ~ 50dBu |
| SNR (Signal to Noise Ratio) | 109dB |
| Maximum Input Level | +20dBu ±0.5dBu |
| Phantom Power (+/-3V) | +48VDC |
| USB stereo inputs | 22Hz ~ 22KHz at 0dBu ±1.5dBu |
| Frequency Response to Main Output | <0.03% at 0dBu 1KHz |
| Distortion (THD&N) to Main Output | 10dBu ±0.5dBu |
| Maximum Input Level | +20dBu ±0.5dBu |
| Out 1-16 | |
| Maximum Outputs Level | +20dBu ±0.5dBu |
| Main Outputs | |
| Maximum Output Level | +20dBu ±0.5dBu |
| Control Room Outputs | |
| Maximum Output Level | +20dBu ±0.5dBu |
| Noise Gate | |
| Threshold Range | -80d0Bu ~ -30dB |
| Attack time | 0.5mS ~ 200mS |
| Release time | 10mS~1S |
| Compressor | |
| Threshold Range | -30dBu - +20dB |
| Attack time | 10mS ~ 150mS |
| Release time | 10mS ~ 1S |
| Ratio | 1:1 to Limit |
| Gain | 0dBu - +20dB |
| EQ | |
| Low (LowPass or LowShelf) | 21Hz ~ 19.2KHz ±(24dBu±2dBu) |
| Low Mid | 21Hz ~ 19.2KHz ±(24dBu±2dBu) |
| High Mid | 21Hz ~ 19.2KHz ±(24dBu±2dBu) |
| High (HighPass or HighShelf) | 21Hz ~ 19.2KHz ±(24dBu±2dBu) |
| Digital Audio | |
| ADC Dynamic Range | 114dB |
| DAC Dynamic Range | 114dB |
| Internal Processor | 32-bit , floating point |
| ADC, DAC bit depth | 24bit |
| Main LCD | 10.1 inch (1024x600) |
| Channel LCD | 0.96 inch (128x64) |
| Impedances | |
| Microphone input | 6.8K Ohm |
| All output | 120 Ohm |
| Operating free-air temperature range | 0ºC ~ 40ºC |
| Storage temperature range | -20ºC ~ 45ºC |
