| Frequency Response | 22Hz ~ 20KHz at 0dBu +1/-2.5dB |
| Distortion (THD&N) | <0.03% at 0dBu 1KHz |
| SNR (Signal to Noise Ratio) | 107dB |
| Maximum XLR Outputs Level | +20dBu ±0.5dB |
| Maximum HeadPhones Output Level | +20dBu ±0.5dB |
| Input to Output Crosstalk (at +0dBu 1KHz) | <-105dBu |
| Adjacent Channels Crosstalk (at +0dBu 1KHz) | <-105dBu |
| Bus Noise | <-89dBu |
| ADC Dynamic Range | 113dB |
| DAC Dynamic Range | 113dB |
| Internal Processor | 32-bit, floating point |
| ADC bit depth | 32bit |
| DAC bit Depth | 24bit |
| Input Impedances | 6.8KΩ |
| Output Impedances | 120Ω |
| Noise Gate | |
| Threshold Range | -84dBu ~ +19dBu |
| Attack time | 0mS ~ 250mS |
| Release time | 5mS ~ 2S |
| Compressor | |
| Threshold Range | -83dBu - +20dBu |
| Attack time | 0mS ~ 250mS |
| Release time | 5mS ~ 2S |
| Ratio | 1:1 to 40:1,inf:1 |
| Gain | 0dB - +12dB |
| EQ | |
| Low (LowPass or LowShelf) | 20Hz ~ 20KHz ± (15dbu ±2dbu) |
| Low Mid | 20Hz ~ 20KHz ± (15dbu ±2dbu) |
| High Mid | 20Hz ~ 20KHz ± (15dbu ±2dbu) |
| High (HighPass or High Shelf) | 20Hz ~ 20KHz ± (15dbu ±2dbu) |
| Dimensions | 349 x 452 x 147mm |
| Weight | 6.7 kg |
