- Custom-designed 15-inch woofer
- 2414H compression driver
- Re-designed high-frequency horn
- Power: 1,300W peak / 650W RMS
- Frequency response: 45 Hz–20 kHz (-10 dB); 55 Hz–20 kHz (-3 dB)
- Max SPL: 128 dB
- Dispersion: 90° H x 60° V
- Audio I/Os: 2 XLR Combo, 1 XLR passthrough
- Advanced dbx DSP: Automatic Feedback Suppression, ducking, 100ms speaker delay, parametric EQ
- Built-in 3-channel digital mixer
- Backlit color LCD screen provides easy access to functions
- Universal JBL Pro Connect app control
- Bluetooth 5.0 streaming and control
- Durable polypropylene cabinet and metal grille
- Two ergonomic handles simplify transport
- Built-in pole mount and optional EON700 Universal Yoke Mount expand system configuration options
- Stackable cabinets allow easy storage
- Dimensions: 27.6 x 17.2 x 13.8 in (702 x 438 x 351 mm) (HxWxD)
- Weight: 37.3 pounds (16.9 kg)
- Shipping dimensions: 29.92 x 21.73 x 18.38 in (760 x 552 x 467 mm) (HxWxD)
- Shipping weight: 49.6 pounds (22.5 kg)
Specifications
| System Type | 15IN Powered Loudspeaker |
| Woofer Model | 715G |
| Woofer Size | 15" |
| Woofer Magnet | Ferrite |
| Woofer Voice Coil | 2" |
| Tweeter Model | 2414H Compression Driver |
| Tweeter Size | 1'' |
| Tweeter Magnet | Neodymium |
| Transducer Impedence | LF 4ohm rated, HF 8ohm rated |
| Max SPL | 128dB @1m/4Pi |
| Freq Range -10 | 45Hz - 20kHz |
| Freq Range -3 | 55Hz - 20kHz |
| Hor Dispersion | 90° |
| Vert Dispersion | 60° |
| Power Rating | 1300W peak / 650 RMS |
| AC power input | 100V-120V or 220V-240V |
| Cooling | Passive |
| LED indicators | 1 Power LED, 1 Limit LED, 1 Front LED, 2 Signal/SSM LEDs |
| Input Impedance | 50k/100k un-balanced/balanced |
| Input Gain | -∞to +36db |
| Crossover Frequency | 1.9 kHz |
| I/O | 2 XLR Combo Jacks / BT 1 XLR M Thru |
| Cabinet | PP+10% Talc |
| Grille | 16GA perforated steel with acoustically transparent black cloth backing |
| Suspension / Mounting | 4 M10 Suspension points, 36mm Pole Socket, universal yoke bracket holes |
| Handles | 2, cable channel on bottom |
| Net Weight | 17kg (37.48 lbs.) |
| Gross Weight | 21.5kg (47.40 lbs.) |
| Product Dims | HxWxL 716x438x358mm (28.19x17.24x11.09 in.) |
| Shipping Dims | HxWxL 738x543x458mm (29.06x21.38x18.03 in.) |
