Frequency Response |
All inputs: 20 Hz – 22 kHz (±1 dB) |
|
THD+N (Total Harmonic Distortion) |
All inputs: < 0.005% (@ 4 dBu, 1 kHz) |
|
Gain Range |
Mic inputs (Channel 1): 0 – 44 dB Line input (Channel 1): 12 – 30 dBu Line inputs (Channels 2/3): 0 dBu |
|
Max Voltage Gain |
74 dB (Mic Input to Main Out and 2TK Output) 80 dB (Mic Input to Phones Output) 30 dB (Line Input to Main Out) |
|
SNR (Signal-to-Noise ratio) |
All inputs: > 110 dBu |
|
Impedance |
Mic inputs: 3.9 kΩ All other inputs: > 10 kΩ 2TK output: 1 kΩ All other outputs: 120 Ω |
|
Crosstalk |
Adjacent inputs: < -80 dB @ 1 kHz Inputs to outputs: < -75 dB @ 1 kHz (stereo L/R, Channel 1, panned hard left or right) |
|
Equalization |
High: ±15 dB @ 12 kHz Low: ±15 dB @ 80 Hz |
|
Connectors |
(2) 1/4” (6.35 mm) TRS outputs (2) 1/4” (6.35 mm) TRS stereo L/R inputs (1) 1/4" (6.35 mm) TRS headphone output (1) 1/4" (6.35 mm) TRS mono input (1) XLR input (1) Stereo RCA L/R input (1) Stereo RCA L/R output (1) USB type-B input (1) DC power input |
|
Controls |
(1) Power switch (6) Volume control knobs (1 per input and output) (3) Gain control knobs (1 per channel) (3) EQ Hi control knobs (1 per channel) (3) EQ Low control knobs (1 per channel) (3) Stereo pan control Knobs (1 per channel) (2) Locking switch buttons |
|
Indicators |
(1) Power LED, (3) Peak LEDs, (8) Main Out meter LEDs |
|
Main Mix |
Main output: (2) 1/4" (6.35 mm) balanced TRS, +22 dBu max output 2TK output: (2) unbalanced RCA, 0 dBu max output Headphone output: (1) stereo 1/4" (6.35 mm) TRS, 160 mW @ 32 Ω |
|
Power |
Connection: DC Voltage: 18V, 500 mA Consumption: 9 W |
|
Dimensions (width x depth x height) |
6.3" x 7.6" x 2.6" 159.5 mm x 193 mm x 66 mm |
|
Weight |
2.0 lbs. 0.9 kg |
