NEUMANN U87 AI

Studio Condenser Microphone

The U 87 is probably the best known and most common Neumann studio microphone.

The U 87 is equipped with a large dual-diaphragm capsule with three directional patterns: omnidirectional, cardioid and figure-8. These are selectable with a switch below the headgrille. A 10 dB attenuation switch is located on the rear. It enables the microphone to handle sound pressure levels up to 127 dB without distortion. Furthermore, the low-frequency response can be reduced to compensate for proximity effect.

• Pressure gradient receiver
• Polar pattern: omnidirectional, cardioid, figure-of-eight
• Switchable 10 dB attenuation
• Nominal impedance 200 Ohm
• Frequency response 20 - 20,000 Hz
• Sound pressure level for k < 0.5%: 117 dB (cardioid)
• Sound pressure level for k < 0.5% with pre-attenuation: 127 dB
• 48 V phantom powering required
• Dimensions (diameter x length): 56 x 200 mm
• Weight: 500 g
• Colour: Nickel
